4.16 Wireless LAN card 4 Replacement Procedures
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-53
Installing the wireless LAN card
The following describes the procedure for installing the wireless LAN card (See Figure 4-33
and 4-34).
1. Insert the wireless LAN card into the connector CN2600 on the system board
slantwise.
2. Secure the wireless LAN card with the following screws while pushing it.
• M2.0×3C BIND screw ×2
3. Connect the wireless LAN antenna cables to the terminals on the wireless LAN card.
NOTE: white cable to MAIN, black cable to AUX for the two antenna cables and white
cable to 1, black cable to 2 and gray cable to 3 marked on the wireless LAN card
for three antenna cables.
