4.17 Back cover 4 Replacement Procedures
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-55
Installing the Back cover
The following describes the procedure for installing the back cover (See Figure 4-35).
1. Set the back cover under the guide of the base assembly.
NOTE: When setting the back cover, be careful not to pinch the DC-IN jack cable and
right LED cable.
2. Secure the back cover with the following screws.
• M2.5×6B FLAT HEAD screw ×4
