4.21 MDC 4 Replacement Procedures
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-63
Installing the MDC
The following describes the procedure for installing the MDC (See Figure 4-39).
1. Connect the modem cable to the connector on the MDC.
2. Connect the MDC to the connector CN3010 on the system board by pressing it
carefully. Be careful not to damage the MDC and connectors.
3. Secure the MDC with the following screws.
• M2.0×4B BIND screw ×2
CAUTION: Remove and connect the MDC from/on the system board perpendicularly,
otherwise it may damage the MDC and connectors.
