4.26 CPU fin/North bridge fin/CPU fan/CPU 4 Replacement Procedures
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-81
7. Set the heat sink holder and secure it with the following screws.
• M2.0×4B BIND screw ×3
NOTE: When securing the heat sink holder, be sure to secure the screws in the order of
the number marked on the holder.
