4.35 LCD unit/FL inverter 4 Replacement Procedures
QOSMIO G50 Maintenance Manual (960-683) [CONFIDENTIAL] 4-105
Installing the LCD unit/FL Inverter
The following describes the procedure for installing the LCD unit/FL inverter (See Figure 4-
66 to 4-70).
1. Connect the LCD cable to the connector on the LCD unit and stick the glass tape in
place.
2. Set the brake hinges (left and right) to the LCD unit and secure them with the
following screws.
• M2.0×4B S-THIN HEAD screw ×8
NOTE: When securing the brake hinges, be sure to secure the screws in the order of the
number marked on the brake hinges.
3. Set the LCD unit to the LCD cover and arrange the cables to the guides.
4. Secure the LCD unit with the following screws.
• M2.5×6B FLAT HEAD screw ×6
5. Connect the LCD cable and HV cables to the connector on the FL inverter.
CAUTION: Be careful not to connect the HV cable to the wrong connectors of the FL
inverter.
6. Set the FL inverter to the slot and secure it with the following screw.
• M2.0×4B S-THIN HEAD screw ×1
7. Set the LCD mask while engaging the latches and secure it with the following
screws.
• M2.5×6B FLAT HEAD screw ×4
• M2.5×8B FLAT HEAD screw ×2
8. Stick six LCD cushions (up and low) in place.
