Appendices Appendix B Board Layout
B-2 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
Table B-1 System board
(F
DUSY
*) connectors
and ICs
(front)
Number Name
CN1920 2
nd
HDD SATA I/F connector
CN2600 PCI-E Mini CARD I/F (W-LAN) connector
CN2650 PCI-E Mini CARD I/F (slot2) connector
CN2700 PCI-E Mini CARD I/F (slot3) connector
CN2711 RF I/F connector
CN3010 MDC I/F connector
CN3011 FM Tuner I/F connector
CN3230 Keyboard I/F connector
CN3240 FDULE* board I/F connector
CN3300 Power SW connector
CN3330 Volume I/F connector
CN3490 It is debugging port for development only
CN4440 Bluetooth2 I/F connector
CN4630 FDUJK* board I/F connector for USB
CN4631 FDUJK* board I/F connector for MIC/HP
CN5310 LCD I/F connector
CN5311 LCD I/F connector
CN6170 SPEAKER Right / subwoofer I/F connector
CN6171 SPEAKER Left I/F connector
CN8800 DC-IN connector
CN9550 Web Camera I/F connector
CN9570 FELICA I/F connector: Japanese model only
CN9650 Touch Sensor I/F connector
CN9700 Left Speaker LED I/F connector
CN9701 Right Speaker LED I/F connector
IC1600 South Bridge ICH9M
