Appendices Appendix C Pin Assignments
C-10 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
Table C-7 PCI TV tuner interface connector (124-pin)(2/2)
Pin No. Signal Name Pin No. Signal Name
61 IRDY-P3N 62 GND
63 P3V 64 FRAME-P3N
65 CLKRUN-P3N 66 TRDY-P3N
67 SERR-P3N 68 STOP-P3N
69 GND 70 P3V
71 PERR-P3N 72 DEVSEL-P3N
73 CBE-P3N 74 GND
75 AD14-P3P 76 AD15-P3P
77 GND 78 AD13-P3P
79 AD12-P3P 80 AD11-P3P
81 AD10-P3P 82 GND
83 GND 84 AD09-P3P
85 AD08-P3P 86 CBE0-P3N
87 AD07-P3P 88 P3V
89 P3V 90 AD06-P3P
91 AD05-P3P 92 AD04-P3P
93 BCRST-P3N 94 AD02-P3P
95 AD03-P3P 96 AD00-P3P
97 P5V 98 P5V
99 AD01-P3P 100 NC
101 GND 102 TMPTUN-GND
103 BCIO-P5P 104 TMPTU1-SXP
105 NC 106 TMPTU2-SXP
107 CPLGP1-P3P 108 NC
109 NC 110 TMPTU1-SXP
111 BCCDET-P3N 112 NC
113 GND 114 GND
115 XBCCLK-P3P 116 GND
117 GND 118 GND
119 GND 120 GND
121 BCPWON-P3P 122 NC
123 P5V 124 NC
