Toshiba QOSMIO G50 Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-35
C.53 DS6320 SPDIF interface connector (10-pin)
Table C-53 SPDIF interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 2
HEADL-PXP
3 HEADR-PXP 4 GND
5 SPDJIN-P3N 6 NC
7 DOUT-P3P 8 SPD3V-P3V
9 GND 10 NC
C.54 J6071 Ext MIC interface connector (5-pin)
Table C-54 Ext MIC interface connector (5-pin)
Pin No. Signal Name Pin No. Signal Name
1
GND
2
EMCINL-PXP
3 EMCINR-PXP 4 GND
5 DETCTA-P4N
