Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-45
Table C-63 System board interface connector (230-pin)(3/4)
Pin No. Signal Name Pin No. Signal Name
141
VSYNCA-P3P
142
GND
143 NVASCL-P5P 144 NVABLU-PXP
145 NVASDA-P5P 146 GND
147 AZSDIH-P3P 148 XLCK1-PYP
149 AZSDO2-P3P 150 XLCK1-PYN
151 GND 152 GND
153 NVBSCL-P5P 154 ZLTX7-PYP
155 NVBSDA-P5P 156 ZLTX7-PYN
157 GACDET-P3P 158 HDMISD-P3P
159 GND 160 ZLTX6-PYP
161 NVCRED-PXP 162 ZLTX6-PYN
163 GND 164 GND
165 NVCGRN-PXP 166 ZLTX5-PYP
167 HSYNCC-P3P 168 ZLTX5-PYN
169 GND 170 GND
171 NVCBLU-PXP 172 ZLTX4-PYP
173 VSYNCC-P3P 174 ZLTX4-PYN
175 GND 176 GND
177 NC 178 XLCK0-PYP
179 NC 180 XLCK0-PYN
181 NC 182 GND
183 NC 184 ZLTX3-PYP
185 NC 186 ZLTX3-PYN
187 GND 188 GND
189 NC 190 ZLTX2-PYP
191 NC 192 ZLTX2-PYN
193 GND 194 GND
195 NC 196 ZLTX1-PYP
197 NC 198 ZLTX1-PYN
199 GND 200 GND
201 NC 202 ZLTX0-PYP
203 NC 204 ZLTX0-PYN
205 HPDCEC-P3P 206 GND
207 XDCTX3-PYN 208 PGV
209 XDCTX3-PYP 210 M5V
211 GND 212 LCDVEN-E5V
213 ZDCTX2-PYN 214 FLPWM-P3P
