Toshiba QOSMIO G50 Maintenance Manual

2 Troubleshooting Procedures 2.4 System Board Troubleshooting
2-26 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
Table 2-8 Debug port error status (5/8)
F124 LAN setup LAN Controller IC4000 (LAN Controller)
setup of ICH (PIC)
setup of ICH (DMAC)
setting error of ICH (PCI Express)
setup of ICH (CMOS)
F125
EC setup
ICH(PIC controller,
DMAC,PCI Ex
pess,
CMOS)
EC/KBC(EC)
IC1600 (ICH)
IC3200 (EC/KBC)
F126 Robson setup Robson CN2650 (Robson)
F127 HDD setup
HDD
ICH(IDE controller)
IC1600 (ICH, HDD Cont.)
CN1900 (HDD Conn.)
CN1920 (HDD Conn.)
F128 Display setup VGA
IC1200 (VGA)
IC5000 (VGA)
F129 setup of RAM data RAM
CN1400 (RAM Conn.)
CN1410 (RAM Conn.)
setup of RAM data
setup of CPU and MCH
CPU setup
FFFF
KBC setup
MCH(PCI register )
CPU
RAM
EC/KBC(KBC)
IS1050 (CPU Socket)
IC1200 (MCH)
CN1400 (RAM Conn.)
CN1410 (RAM Conn.)
IC3200 (EC/KBC)
