viii [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)

3.26 Wireless LAN Test Program (Intel-made b/g ,a/b/g)............................................... 3-57

3.27 Wireless LAN Test Program (Intel-made a/b/g/n)................................................... 3-61

3.28 LAN/Modem/Bluetooth/IEEE1394 Test Program ..................................................3-65

3.29 Sound Test program.................................................................................................3-77

3.30 SETUP .....................................................................................................................3-78

Chapter 4 Replacement Procedures

4.1 Overview....................................................................................................................4-1

4.2 Battery pack ...............................................................................................................4-8

4.3 ExpressCard & PC card / Bridge media ..................................................................4-11

4.4 HDD......................................................................................................................... 4-14

4.5 Memory module....................................................................................................... 4-18

4.6 Fan hood...................................................................................................................4-20

4.7 Keyboard..................................................................................................................4-21

4.8 MDC ........................................................................................................................4-24

4.9 Bluetooth module..................................................................................................... 4-26

4.10 Wireless LAN card ..................................................................................................4-28

4.11 Cover assembly/Base assembly...............................................................................4-32

4.12 Speaker.....................................................................................................................4-38

4.13 Woofer .....................................................................................................................4-40

4.14 USB/Jack board .......................................................................................................4-41

4.15 Battery lock/Battery latch ........................................................................................4-43

4.16 Optical disk drive.....................................................................................................4-44

4.17 AV-IN board/F-jack/Rear con cover .......................................................................4-47

4.18 Splitter/TV antenna holder.......................................................................................4-51

4.19 1

tuner.....................................................................................................................4-55

4.20 2

tuner....................................................................................................................4-56

4.21 RTC battery..............................................................................................................4-57

4.22 1bit amp ...................................................................................................................4-59

4.23 LED board................................................................................................................4-60

4.24 Touch pad/Fingerprint sensor board........................................................................4-61

4.25 Cover latch...............................................................................................................4-64
