Toshiba Tecra S3 Maintenance Manual

2 Troubleshooting Procedures
2-64 [CONFIDENTIAL] TECRA S3 Maintenance Manual (960-532)
This section describes how to check PCI ExpressCard slot by inspecting a card with PCI
Express interface and a card with USB 2.0 interface.
1. Gigabit Ether ExpressCard
2. USB2.0 5in1 ExpressCard
1. Gigabit Ether ExpressCard
(1) Insert the Gigabit Ether ExpressCard into the ExpressCard slot.
(2) On Windows, open System Property → Hardware → Device Manager window.
(3) Make sure that the following device is recognized on the Device Manager window.
Marvell Yukon 88E8053E PCI-E Gigabit Ethernet Controller #2
(“#2” is displayed in the PC with a built-in LAN of Gigabit, because the controller is
the same one. “#2” is not displayed in the PC with a built-in LAN of 10/100
Megabit.)
(4) After making sure, take a “Safety Remove” procedure and pull out the Gigabit Ether
ExpressCard
2. USB2.0 5in1 ExpressCard
(1) Insert the USB2.0 5in1 ExpressCard into the ExpressCard slot.
(2) On Windows, open System Property →Hardware → Device Manager window.
(3) Make sure that the following device is recognized on the Device Manager window.
USB 2.0 5in1 ExpressCard USB Device
(4) After making sure, take a “Safety Remove” procedure and pull out the USB2.0 5in1
ExpressCard.
Formatted:
Numbered + Level: 1 +
Numbering Style: 1, 2, 3, … + Start
at: 1 + Alignment: Left + Aligned at:
14.2 pt + Tab after: 32.2 pt + Indent
at: 32.2 pt, Tabs: 18 pt, Left
Formatted:
Numbered + Level: 1 +
Numbering Style: 1, 2, 3, … + Start
at: 1 + Alignment: Left + Aligned at:
14.2 pt + Tab after: 32.2 pt + Indent
at: 32.2 pt, Tabs: 18 pt, Left
Formatted:
Numbered + Level: 1 +
Numbering Style: 1, 2, 3, … + Start
at: 1 + Alignment: Left + Aligned at:
14.2 pt + Tab after: 32.2 pt + Indent
at: 32.2 pt, Tabs: 18 pt, Left
Formatted:
Numbered + Level: 1 +
Numbering Style: 1, 2, 3, … + Start
at: 1 + Alignment: Left + Aligned at:
14.2 pt + Tab after: 32.2 pt + Indent
at: 32.2 pt, Tabs: 18 pt, Left

Toshiba Tecra S3 Specifications

General

Processor cache	2 MB
Processor frequency	2.26 GHz
Processor cache type	L2
Processor front side bus	533 MHz
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	100 GB
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	2 GB
Memory layout (slots x size)	2 x 0.5 GB
Maximum resolution	2048 x 1536 pixels
Discrete graphics card model	NVIDIA GeForce Go 6600
Maximum graphics card memory	0.128 GB
Display diagonal	15 \
Display resolution	1400 x 1050 pixels
Native aspect ratio	4:3
Motherboard chipset	Intel® 915PM Express
CD-R write speed	24 x
DVD+R read speed	8 x
DVD+R write speed	4 x
DVD-RW write speed	2 x
DVD+R Double Layer write speed	2.4 x
Supported audio standards	MIDI
Number of built-in speakers	2
Front camera	No
Modem speed	56 Kbit/s
Wireless technology	Bluetooth
Disc types supported	CD-R, CD-ROM, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RAM, DVD-ROM, DVD-RW
Networking type	802.11b/g
Networking features	10/100/1000 Base-TX
Bundled software	- Microsoft Office OneNote 2003; - Sonic Record Now!; - InterVideo WinDVD; - Norton Internet Security 2005 (incl. 90 dagen gratis Internet-updates); - Toshiba RAID software; - Toshiba Management Console; - ConfigFree.
Operating system installed	Windows XP Professional
TV-out type	S-Video
Charging port type	DC-in jack
PS/2 ports quantity	0
USB 2.0 ports quantity	3
Parallel ports quantity	1
CardBus PCMCIA slot type	Type II
Pointing device	Touchpad + Accupoint II
Keyboard number of keys	86
Certification	S.M.A.R.T.
External video modes refresh rate (max)	100 Hz
External video modes non-interlaced resolution with max. refresh rate	1600 x 1200 pixels
AC adapter input voltage	100/240 V

Weight and Dimensions

Depth	280 mm
Width	338 mm
Height	29.7 mm
Weight	2850 g
