Appendix C Pin Assignments Appendices
TECRA S3 Maintenance Manual (960-532) [CONFIDENTIAL] C-29
C.30 CN8020 Main Battery connector (10-pin)
Table C-30 Main Battery connector (10-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 PVBL1 - 2 BTMP1 I
3 (DCHG) - 4 M5V -
5 PSCL-S5P I/O 6 PSDA-S5P I/O
7 GND - 8 DBT10V-S5N O
9 GND - 10 GND -
C.31 CN9990 RTC Battery connector (3-pin)
Table C-31 RTC Battery connector (3-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 ZS-PWCHKF O 2 NC -
3 GND -
1T GND - 2T GND -
C.32 CN8770 FAN connector (3-pin)
Table C-32 FAN connector (3-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 (P5V) O 2 GND -
3 FANG-P3P I
C.33 CN9700 FS board interface connector (8-pin)
Table C-33 FS board interface connector (8-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 GND - 2 USBP0-E5P I/O
3 USBP0-E3N I/O 4 GND -
5 FGSPON-S3N 6 P3V -
7 NC - 8 NC -
1T GND - 2T GND -
