Toshiba Tecra S3 - SR Board (FDRSR*) Front and Back View

Appendices Appendix B Board Layout
B.4 SR Board (FDRSR*) Front and Back View
(C)
(B)
(A)
(front)
(back)
Figure B-4 SR Board (FDRSR*) layout (front/back)
Table B-4 SR Board (FDRSR*) connectors
Mark Number Name
(A) CN9510 System board I/F connector
(B) CN3420 Serial port
(C) CN4630 USB 6 connector
B-6 [CONFIDENTIAL] TECRA S3 Maintenance Manual (960-532)
