Toshiba Tecra S3 Maintenance Manual

Tests and Diagnostics
TECRA S3 Maintenance Manual (960-532) [CONFIDENTIAL] 3-97
3.30.2 CD Sound (Standard) test
To execute the CD Sound (Standard) test, press 3 and Enter. Insert the test media
(TOSHIBA TEST CD-ROM or ABEX TEST CD-ROM) or music CD on the market (if the
test media can not be prepared). Following menu appears in the display.
For details on use of test media, refer to 3.30.3.1 Test media (Toshiba-made test media).
For details on use of audio CD on the market, refer to 3.30.3.2 Audio CD.
3.30.3.1 Test media (Toshiba-made test media)
CD/DVD TEST IN PROGRESS XXXXXXXX
xxxxxxx DIAGNOSTIC TEST VX.XX
[Ctrl]+[Break] : test end
[Ctrl]+[C] : key stop
SUB-TEST : XX
PASS COUNT : XXXXX ERROR COUNT : XXXXX
WRITE DATA : XX READ DATA : XX
ADDRESS : XXXXXX STATUS : XXX
01 – Japanese Narration
02 – English Narration
03 – Test Tone A (100Hz – 20Hz)
04 - Test Tone B (400Hz – 3KHz L-R)
Drive # = 0, ATAPI status =00
Command = XX
[[Block address = XXXXXXXX]]
[[Block length = XXXXXXXX]]
Final : Block address = XXXXXXXXX
Subtest01 Japanese Narration
Selected this subtest, narration in Japanese starts and following message
appears in the display.
Play start CD sound !
Press any key <Play stop>.
Press any key and stop the narration. Then return to the CD Sound (Standard)
test menu.
Subtest02 English Narration
Selected this subtest, narration in English starts.
For more details on the procedure, refer to the subtest01.
Formatted:
Bullets and
Numbering

Toshiba Tecra S3 Specifications

General

Processor cache	2 MB
Processor frequency	2.26 GHz
Processor cache type	L2
Processor front side bus	533 MHz
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	100 GB
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	2 GB
Memory layout (slots x size)	2 x 0.5 GB
Maximum resolution	2048 x 1536 pixels
Discrete graphics card model	NVIDIA GeForce Go 6600
Maximum graphics card memory	0.128 GB
Display diagonal	15 \
Display resolution	1400 x 1050 pixels
Native aspect ratio	4:3
Motherboard chipset	Intel® 915PM Express
CD-R write speed	24 x
DVD+R read speed	8 x
DVD+R write speed	4 x
DVD-RW write speed	2 x
DVD+R Double Layer write speed	2.4 x
Supported audio standards	MIDI
Number of built-in speakers	2
Front camera	No
Modem speed	56 Kbit/s
Wireless technology	Bluetooth
Disc types supported	CD-R, CD-ROM, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RAM, DVD-ROM, DVD-RW
Networking type	802.11b/g
Networking features	10/100/1000 Base-TX
Bundled software	- Microsoft Office OneNote 2003; - Sonic Record Now!; - InterVideo WinDVD; - Norton Internet Security 2005 (incl. 90 dagen gratis Internet-updates); - Toshiba RAID software; - Toshiba Management Console; - ConfigFree.
Operating system installed	Windows XP Professional
TV-out type	S-Video
Charging port type	DC-in jack
PS/2 ports quantity	0
USB 2.0 ports quantity	3
Parallel ports quantity	1
CardBus PCMCIA slot type	Type II
Pointing device	Touchpad + Accupoint II
Keyboard number of keys	86
Certification	S.M.A.R.T.
External video modes refresh rate (max)	100 Hz
External video modes non-interlaced resolution with max. refresh rate	1600 x 1200 pixels
AC adapter input voltage	100/240 V

Weight and Dimensions

Depth	280 mm
Width	338 mm
Height	29.7 mm
Weight	2850 g
