Toshiba Tecra S3 - CN3010 Modem Connector (12-Pin; CN3011 Modem Relay Connector (4-Pin

Appendix C Pin Assignments Appendices
TECRA S3 Maintenance Manual (960-532) [CONFIDENTIAL] C-17
Table C-8 Docking interface connector (240-pin) (4/4)
Pin No. Signal Name I/O Pin No. Signal Name I/O
223 NC - 224 NC -
225 GND - 226 NC -
227 NC - 228 NC -
229 GND 230 NC -
231 NC - 232 NC -
233 GND - 234 ACT-E3N I
235 LINK-E3N I 236 DOCDT2-S3N I
237 Not mounted - 238 Not mounted -
239 BIDBP-EXP O 240 BIDBN-EXN O
1T GND - 2T GND -
3T GND - 4T GND -
5T GND - 6T GND -
7T GND - 8T GND -
9T GND - 10T GND -
C.9 CN3011 Modem relay connector (4-pin)
Table C-9 Modem relay connector (4-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1
MDMRNG-E3P
I/O
2
MDMRNG-E3P
I/O
3
MDMIP-E3P
I/O
4
MDMIP-E3P
I/O
C.10 CN3010 Modem connector (12-pin)
Table C-10 Modem connector (12-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1
GND
-
2
NC
-
3
ACZOT2-P3P
I/O
4
NC
-
5
GND
-
6
E3V
-
7
ACZSY2-P3P
-
8
GND
-
9
ACZIN2-E3P
I/O
10
GND
-
11
ACZRS2-E3N
-
12
XAZBCM-P3P
I
1T
GND
-
2T
GND
-
3T
GND
-
4T
GND
-
5T
GND
-
6T
GND
-
