4.9 Keyboard
Removing the Keyboard
To remove the keyboard, follow the steps below and refer to Figure 4-10 to 4-13.
1. Turn the computer face up.
2. Open the display and make it flat.
3. Insert your finger into the latches of the both sides and lift up the speaker cover to
remove.
4. Remove the following screws.
• M2.5×4B FLAT HEAD screw ×2
Speaker cover
M2.5×4B FLAT HEAD
M2.5
4B FLAT HEAD
Figure 4-10 Removing the speaker cover
4-22 [CONFIDENTIAL] TECRA S3 Maintenance Manual (960-532)
