Toshiba Tecra S3 - CN950 System Board Interface Connector (8-Pin

Appendix C Pin Assignments Appendices
TECRA S3 Maintenance Manual (960-532) [CONFIDENTIAL] C-31
FDRFS Board
C.37 CN950 System board interface connector (8-pin)
Table C-37 System board interface connector (8-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 NC - 2 NC -
3 P3V - 4 FGSPON-S3N I
5 GND - 6 USBFS-E3N I/O
7 USBFS-E3P I/O 8 GND -
1T GND - 2T GND -
