1 Hardware Overview
1.2 2.5-inch Hard Disk Drive
The HDD is a random access non-volatile storage device. The computer supports a 40GB,
60GB, 80GB and 100GB HDD.
The HDD is shown in figure 1-4. Specifications are listed in Table 1-1.
Figure 1-4 2.5-inch HDD
Table 1-1 2.5-inch HDD specifications (1/2)
Specifications
Items
FUJITSU
G8BC00028410
FUJITSU
G8BC00028610
FUJITSU
G8BC00028810
FUJITSU
G8BC00028A1
0
Outline
Width (mm)
70
dimensions
Height (mm)
9.5
Depth (mm)
100
Weight (g)
96 max. 101 max.
Storage size (formatted) 40GB 60GB 80GB 100GB
Speed (RPM) 5,400
Data transfer rate
To/From media (MB/s)
To/From host (Gbps)
64.0 max.
1.5 (150 MB/s) max.
Data buffer size (MB) 8
Average seek time
Read (ms)
12 typ.
Motor startup time (s) 4 typ.
