TRANSPORTATION AND INSTALLATION MANUAL
• When lifting up the robot by workers, hold the locations (shaded areas) by
hands as shown in Fig. 2.4. If the arm 2, cover or ball screw spline shaft is
held by hands, an unusually large force is exerted, resulting in a
malfunction.
• When carrying the robot by workers, take careful precautions to prevent
their hand or leg from being caught in the robot.
• The work should be performed by two (2) or more workers.
2.2.3 Transporting the Controller
Disconnect all cables and teach pendant before transporting the controller.
• When placing the controller on the floor, etc., make sure not to have your
hands or feet caught.
STE 85305
