Toshiba TH650A - Tool Air Piping

TRANSPORTATION AND INSTALLATION MANUAL
The air tube is identified by the number and color. At piping, make sure that each
tube is connected properly, referring to the below-mentioned.
1 : Red 2 : White 3 : Blue 4 : Yellow
Fig. 5.7 Tool air piping
D-SUB connector
Cannon connector (option)
STE 85305
