Toshiba TOSVERT VF-nC3 User Manual

E6581595
F-14
6
6.5.3 Setting of frequency with the input from an external logic
 : External logic input - UP response time
 : External logic input - UP frequency steps
 : External logic input - DOWN response time
 : External logic input - DOWN frequency steps
 : Initial value of UP/DOWN frequency
 : Change of the initial value of UP/DOWN frequency
 Function
These parameters are used to set an output frequency by means of a signal from an external device.
[Parameter setting]
Title Function Adjustment range Default setting

External logic input - UP response
time
0.0 - 10.0 (S) 0.1

External logic input - UP frequency
steps
0.0 -  (Hz) 0.1

External logic input - DOWN response
time
0.0 - 10.0 (S) 0.1

External logic input - DOWN frequency
steps
0.0 -  (Hz) 0.1

Initial value of UP/DOWN frequency  -  (Hz) 0.0

Change of the initial value of
UP/DOWN frequency
0: Not changed
1: Setting of  changed
when power is turned off
1
 This function is valid when the parameter (frequency setting mode selection) =  is set.
■ Input terminal settings
Assign the following functions to the input terminal, you can change (up/down) or clear the output frequency
by using the terminal's ON/OFF.
Input terminal function ON OFF
88 Frequency UP Frequency setting increase Clear
90 Frequency DOWN Frequency setting decrease Clear
92 Clear frequency UP/DOWN
OFF  ON: External logic up/down
frequency Clear settings
 settings
Each of the following numbers (89, 91, 93) are reverse signals.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
