Toshiba TOSVERT VF-nC3 User Manual

E6581595
C-13
3
3.4 Meter setting and adjustment
 : Meter selection
 : Meter adjustment gain
 Function
Output of 0 - 1mAdc, 0 (4) - 20mAdc, 0 - 10vdc can be selected for the output signal from the FM
terminal, depending no the  setting. Adjust the scale at .
Use an ammeter with a full-scale 0 - 1mAdc meter.
The  (analog output bias) needs to be adjusted if output is 4 - 20mAdc.
[Parameter setting]
Title Function Adjustment range
Supposition output at
fsl=17
Default setting

Meter
selection
0: Output frequency
1: Output current
2: Frequency command value
3: Input voltage (DC detection)
4: Output voltage (command value)
5 to 11: -
12: Stator frequency
13: VI input value
14: -
15: Fixed output 1 (output current 100%
equivalent)
16: Fixed output 2 (output current 50%
equivalent)
17: Fixed output 3 (other than the
output current)
18: RS485 communication data
19: For adjustments ( set value is
displayed.)
20 to 22: -
Maximum frequency ()
-
Maximum frequency (fh)
1.5x rated voltage
1.5x rated voltage
-
Maximum frequency (fh)
Maximum input value
-
-
-
-
Maximum value (100.0%)
-
-
0

Meter
adjustment
gain
- - -

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
