Toshiba TOSVERT VF-nC3 User Manual

E6581595
F-9
6
6.4 Basic parameters 2
6.4.1 Switching motor characteristics via terminal input
 : Base frequency 2
 : Base frequency voltage 2
 : Torque boost value 2
 : Motor electronic-thermal protection level 2
 : Stall prevention level 2
 Function
Use the above parameters to switch the operation of two motors with a single inverter and to select
motor V/F characteristics (two types) according to the particular needs or operation mode.
Note: The  (V/F control mode selection) parameter is enabled only for motor1.
If motor 2 is selected, V/F control will be given constant torque characteristics.
[Parameter setting]
Title Function Adjustment range Default setting

Base frequency 2 25.0-400.0 (Hz) *1

Base frequency voltage 2 50-330 (V) *1

Torque boost value 2 0.0-30.0 (%)
Depending on model
(Refer to section 11.4)

Motor electronic-thermal
protection level 2
10-100 (%) / (A) *2 100

Stall prevention level 2
10-199 (%) / (A), *2
200 : Disabled
150
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*2: The inverter's rated current is 100%. When  (current and voltage unit selection)
=  (A (amps)/V (volts)) is set, it can be set at A (amps).

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
