Toshiba TOSVERT VF-nC3 User Manual

E6581595
E-2
5
Parameter
display






Press the MODE key to return to the parameter setting mode
“.”
After that you can press the MODE key to return to the status
monitor mode or the standard monitor mode (display of output
frequency).
Note: The following parameters are not displayed in this auh, even if they are the most recent changes.
 (Operation frequency of operation panel),  (Guidance function),  (Automatic
acceleration/deceleration),  (Torque boost setting macro function),  (Default setting), 
(Checking the region setting),  (Prohibition of change of parameter settings)
5.2 Setting a parameter using the guidance function
()
 : Guidance function
[Parameter setting]
Title Function Adjustment range Default setting

Guidance function
0: -
1: - Note 1
2: Preset speed guidance
3: Analog signal operation guidance
4: Motor 1/2 switching operation guidance
5: Motor constant setting guidance
0
Note: 1 is for manufacturer's settings. Do not change the settings.
MODE
MODE
MODE
Guidance function ():
The guidance function refers to the special function of calling up only functions necessary to set up the inverter in
response to the user’s needs. When a purpose-specific guidance is selected, a group of parameters needed for the
specified application (function) is formed and the inverter is switched automatically to the mode of setting the group
of parameters selected. You can set up the inverter easily by simply setting the parameters in the group one after
another. The guidance function () provides four purpose-specific guidance.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
