Toshiba TOSVERT VF-nC3 User Manual

E6581595
C-4
3
3.2 Simplified Operation of the VF-nC3
Operation command and Operation frequency command are necessary to operate the inverter.
Operation method and operation frequency setting can be selected from the following.
At default setting, the inverter runs and stops with RUN/STOP key on the panel keypad, and frequency can be set
with the setting dial.
Run / Stop
:
(1) Run and stop using the panel keypad
(2) Run and stop using external signals to terminal
board
Setting the frequency
:
(1) Setting using setting dial
(2) Setting using external signals to terminal board
(0-5V/0-10Vdc, 4-20mAdc)
Use the basic parameters  (command mode selection) 
and (frequency setting mode selection) for selection.
[Parameter setting]
Title Function Adjustment range Default setting

Command mode selection
0: Terminal board
1: Panel keypad (including extension
panel)
2: RS485 communication
1

Frequency setting mode
selection
0: Terminal board VI
1: Setting dial 1 (press in center to save)
2: Setting dial 2 (save even if power is off)
3: RS485 communication
4: -
5: UP/DOWN form external logic input
2
● When frequency setting by an extension panel option, fmod is set to 1 or 2.
● fmod=2 (setting dial 2) is the mode where after the frequency is set by the setting dial, the frequency is
saved even if the power is turned off.
● Refer to section 5.5 for details about = and .

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
