Toshiba TOSVERT VF-nC3 User Manual

E6581595
C-3
3
 Values set by each setup parameter
Title Function

(Mainly in
Europe)

(Mainly in North
America)

(Mainly in Asia,
Oceania)

(Mainly in Japan)
 Maximum
frequency
50.0(Hz) 60.0(Hz) 50.0(Hz)
80.0(Hz)
/
/

Frequency
settings
50.0(Hz) 60.0(Hz) 50.0(Hz)
60.0(Hz)
 VI input point 2
frequency
50.0(Hz) 60.0(Hz) 50.0(Hz)
60.0(Hz)
/

Base frequency
voltage 1, 2
230(V) 230(V) 230(V) 200(V)
 Sink/source
switching
 Supply voltage
correction
(output voltage
limitation)
2 2 2 3
 Motor rated
speed
1410(min
-1
) 1710(min
-1
) 1410(min
-1
) 1710(min
-1
)
F, R, S1, S2
CC
0 [ Sink logic ]
(Negative common)
(Common : CC)
F
,
R
,
S1
,
S2
P24
100 [ Source logic ]
(Positive common)
(Common : P24)

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
