Toshiba TOSVERT VF-nC3 User Manual

E6581595
K-15
11
11.4 Default settings by inverter rating
Inverter type
Torque boost
value
Automatic
torque boost
value
Motor rated
capacity
Motor rated
current
Motor no-load
current
／
(%)

(%)

(kW)

(A)

(%)
VFNC3-2001P 6.0 10.3 0.10 0.6 75
VFNC3-2002P 6.0 8.3 0.20 1.2 70
VFNC3-2004P 6.0 6.2 0.40 2.0 65
VFNC3-2007P 6.0 5.8 0.75 3.4 60
VFNC3-2015P 6.0 4.3 1.50 6.2 55
VFNC3-2022P 5.0 4.1 2.20 8.9 52
VFNC3-2037P 5.0 3.4 4.00 14.8 48
VFNC3S-2001PL 6.0 10.3 0.10 0.6 75
VFNC3S-2002PL 6.0 8.3 0.20 1.2 70
VFNC3S-2004PL 6.0 6.2 0.40 2.0 65
VFNC3S-2007PL 6.0 5.8 0.75 3.4 60
VFNC3S-2015PL 6.0 4.3 1.50 6.2 55
VFNC3S-2022PL 5.0 4.1 2.20 8.9 52
VFNC3S-1001P 6.0 10.3 0.10 0.6 75
VFNC3S-1002P 6.0 8.3 0.20 1.2 70
VFNC3S-1004P 6.0 6.2 0.40 2.0 65
VFNC3S-1007P 6.0 5.8 0.75 3.4 60
11.5 Default settings by setup menu
Setting Main regions
Max. frequency Frequency
Base frequency
voltage 1 & 2
Sink/source
switching
Supply voltage
correction
(output voltage
Iimitation)
Motor rated speed

(Hz)
,,
,
(Hz)
, 
(V)
 

(min
-1
)
 Japan 80.0 60.0 200 0 (Sink) 3 1710
 North America 60.0 60.0 230 0 (Sink) 2 1710
 Asia 50.0 50.0 230 0 (Sink) 2 1410
 Europe 50.0 50.0 230 100 (Source) 2 1410

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
