Toshiba TOSVERT VF-nC3 User Manual

E6581595
K-14
11
 Communication parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0800
Baud rate - - 3: 9600bps
4: 19200bps
5: 38400bps
4 6.19

0801
Parity - - 0: NON (No parity)
1: EVEN (Even parity)
2: ODD (Odd parity)
1

0802
Inverter number - 1/1 0-247 0

0803
Communication
time-out time
s 0.1/0.1 0.0: Disabled,
0.1-100.0
0.0

0804
Communication
time-out action
- - 0: Alarm only
1: Trip (Coast stop)
2: Trip (Deceleration stop)
0

0805
Communication
waiting time
s 0.01/0.01 0.00-2.00 0.00

0808
Communication
time-out detection
condition
- - 0: Valid at any time
1: Communication selection of
fmod or cmod
2: 1 + during operation
1

0829
Selection of
communication
protocol
- - 0: Toshiba inverter protocol
1: Modbus RTU protocol
0

0870
Block write data 1 - - 0: No selection
1: Command information
2: -
3: Frequency command value
4: Output data on the terminal board
5: Analog output for communication
0

0871
Block write data 2 - - 0

0875
Block read data 1 - - 0: No selection
1: Status information
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal board monitor
8: Output terminal board monitor
9: VI terminal board monitor
0

0876
Block read data 2 - - 0

0877
Block read data 3 - - 0

0878
Block read data 4 - - 0

0879
Block read data 5 - - 0

0880
Free notes - 1/1 0-65535 0 6.20

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
