10. Peripheral devices
Warning
Prohibited
 When supplying power from a wall socket, do not exceed the rated capacity of the socket.
Otherwise, this may generate excessive heat which can start a fire.
Mandatory
action
 When using switchgear for the inverter, it must be installed in a cabinet.
Failure to do so can lead to risk of electric shock and can result in death or serious injury.
Be Grounded
 Connect grounding cables securely.
Failure to do so can lead to risk of electric shock or fire in case of a failure or short-circuit or electric
leak.
10.1 Selection of wiring materials and devices
Voltage class
Capacity of
applicable
motor (kW)
Inverter model
Wire size (See Note 4)
Power circuit
(mm
2
) (Note 1.)
DC reactor
(optional) (mm
2
)
Grounding cable
(mm
2
)
IEC
compliant
For Japan
(JEAC800
1-2005)
IEC
compliant
For Japan
(JEAC800
1-2005)
IEC
compliant
For Japan
(JEAC800
1-2005)
Three-phase
240V class
0.1 VFNC3-2001P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.2 VFNC3-2002P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.4 VFNC3-2004P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.75 VFNC3-2007P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
1.5 VFNC3-2015P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
2.2 VFNC3-2022P 2.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
4.0 VFNC3-2037P 4.0(2.5) 2.0(2.0) 4.0 2.0 4.0 3.5
Single-phase
240V class
0.1 VFNC3S-2001PL 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.2 VFNC3S-2002PL 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.4 VFNC3S-2004PL 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.75 VFNC3S-2007PL 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
1.5 VFNC3S-2015PL 2.5(2.5) 2.0(2.0) 1.5 2.0 2.5 2.0
2.2 VFNC3S-2022PL 4.0(4.0) 2.0(2.0) 1.5 2.0 4.0 3.5
Single-phase
120V class
0.1 VFNC3S-1001P 1.5 2.0 - - 2.5 2.0
0.2 VFNC3S-1002P 1.5 2.0 - - 2.5 2.0
0.4 VFNC3S-1004P 2.5 2.0 - - 2.5 2.0
0.75 VFNC3S-1007P 4.0 2.0 - - 4.0 3.5
Note 1: Sizes of the wires connected to the input terminals R/L1, S/L2 and T/L3 and the output terminals U/T1,
V/T2 and W/T3 when the length of each wire does not exceed 30m.
The numeric values in parentheses refer to the sizes of wires to be used when a DC reactor is connected.
Note 2: For the control circuit, use shielded wires 0.75 mm
2
or more in diameter.
Note 3: For grounding, use a cable with a size equal to or larger than the above.
Note 4: The wire sizes specified in the above table apply to HIV wires (cupper wires shielded with an insulator
with a maximum allowable temperature of 75°C) used at an ambient temperature of 50°C or less.
Note 5: If there is a need to bring the inverter into UL compliance, use wires specified in chapter 9.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
