E6581595
D-1
4
4. Setting parameters
4.1 Setting and Display Modes
The VF-nC3 has the following three display modes.
Standard monitor mode The standard inverter mode. This mode is enabled when
inverter power goes on.
Setting monitor mode The mode for setting inverter parameters.
How to set parameters, refer to section 4. 2.
There are two parameter read modes. Refer to section 4. 2 for details about
selection and switching of modes.
Easy setting mode : Only the seven most frequently used parameters are
displayed.
Parameters can be registered as necessary. (max. 24
parameters)
Standard setting mode : Both basic and extended all parameters are displayed.
Each press of the EASY key switches between the Easy setting mode and the
Standard setting mode.
This mode is for monitoring the output frequency and setting the frequency reference value. If also
displays information about status alarms during running and trips.
Display of output frequency, etc.
f710 Initial panel display selection
(f720 Initial extension panel display selection)
f702 Free unit display scale
Setting frequency reference values.
Status alarm and trip
If there is an error in the inverter, the alarm signal or the trip signal be displayed in the LED
display.
