E6581595
F-53
6
6.17 Adjustment parameters
6.17.1 Pulse train output for meters
: Logic output/pulse train output selection (OUT)
: Pulse train output function selection (OUT)
: Maximum numbers of pulse train
Function
Pulse trains can be sent out through the OUT output terminals.
To do so, it is necessary to select a pulse output mode and specify the number of pulses.
Ex.: When operations frequencies (0 to 60Hz) are put out by means of 0 to 600 pulses
=60.0, =1, =0, =0.60
[Parameter setting]
Title Function Adjustment range
Reference
of maximum
value of
Default
setting
Logic output/pulse train
output selection (OUT)
0: Logic output
1: Pulse train output
– 0
Pulse train output function
selection (OUT)
0: Output frequency
1: Output current
2: Frequency command value
3: Input voltage (DC detection)
4: Output voltage (command value)
5 to11: -
12: Stator frequency
13: VI input value
14: -
15: Fixed output 1
(Output current: 100% equivalent)
16: Fixed output 2
(Output current: 50% equivalent)
17: Fixed output 3
(Other than the output current)
18: RS485
communication data
19-22: -
185%
150%
150%
-
10 V/20 mA
-
185%
185%
100%
100.0%
-
0
Maximum numbers of
pulse train
0.50-1.60 (kpps)
– 0.80
Digital panel meter for reference
Type: K3MA-F (OMRON)
Connection terminal: OUT-E4, NO-E5
Note 1: When item of f676 reaches “Reference of max. value”, the number of pulse train set by f677
are sent to output terminals (OUT)
Note 2: The pulse ON/OFF duty ratio is fixed at 50%.
Note 3: The minimum pulse output rate is 25pps. Keep in mind that no pulses can be put out at any rate
smaller than 25pps.
Note 4: = is the motor drive frequency.
