Toshiba TOSVERT VF-nC3 User Manual

E6581595
F-52
6
6.16.13 VI analog input break detection
 : VI analog input break detection level
 Function
The inverter will trip if the VI value remains below the specified value for about 0.3 seconds. In such a
case, "" is displayed.
=0: Disabled....Not detected.
=1-100....The inverter will trip if the VI input remains below the specified value for about 0.3 seconds.
[Parameter setting]
Title Function Adjustment range Default setting

VI analog input break detection level
0: Disabled
1-100%
0
Note : The VI input value may be judged earlier to be abnormal, depending on the degree of deviation of the
analog data detected.
6.16.14 Parts replacement alarms
 : Annual average ambient temperature (Parts replacement alarms)
 Function
You can set the inverter so that it will calculate the remaining useful lives of the cooling fan, main
circuit capacitor and on-board capacitor from the ON time of the inverter, the operating time of the
motor, the output current (load factor) and the setting of , and that it will display and send out
an alarm through output terminals when each component is approaching the time of replacement.
[Parameter setting]
Title Function Adjustment range Default setting

Annual average ambient temperature
(parts replacement alarms)
1: -10 to +10C
2: 11-20C
3: 21-30C
4: 31-40C
5: 41-50C
6: 51-60C
3
 Display of part replacement alarm information
Part replacement alarm information (Refer to page H-4) in the Status monitor mode allows you to check
on the time of replacement.
An example of display: 
 Output of part replacement alarm signal
The parts replacement alarm is assigned to the output terminal.
Setup example) When the parts replacement alarm is assigned to the OUT terminal
Title Function Adjustment range Setting

Output terminal selection 1A
(OUT)
0 - 255
128: LTA (Parts replacement
alarm)
Setting value 129 is reverse signal.
Note 1: Using  enter the annual average temperature around the inverter. Be careful not to enter the
annual highest temperature
Note 2: Set  at the time of installation of the inverter, and do not change its setting after the start of
use. Changing the setting may cause parts replacement alarm calculation error.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
