[Trip information]
Error code Failure code Name Description Remedies

000B Overvoltage during
deceleration
 The deceleration time  is too short.
(Regenerative energy is too large.)
 Increase the deceleration time .
 Overvoltage limit operation  is set
to 1. (Disabled).
 Set overvoltage limit operation 
to 0, 2, 3.
 The input voltage fluctuates abnormally.
(1) The power supply has a capacity of
200kVA or more.
(2) A power factor improvement capacitor is
opened and closed.
(3) A system using a thyristor is connected
to the same power distribution line.
 Insert a suitable input reactor.

000C Overvoltage during
constant-speed
operation
 The input voltage fluctuates abnormally.
(1) The power supply has a capacity of
200kVA or more.
(2) A power factor improvement capacitor is
opened or closed.
(3) A system using a thyristor is connected
to the same power distribution line.
 Insert a suitable input reactor.
 The motor is in a regenerative state
because the load causes the motor to run
at a frequency higher than the inverter
output frequency.
 Install an optional brake module.

000D Inverter overload
 The acceleration time ACC is too short.  Increase the acceleration time .
 The DC braking amount is too large.  Reduce the DC braking amount 
and the DC braking time .
 The V/F setting is improper.  Check the V/F parameter setting.
 A restart signal is input to the rotating
motor after a momentary stop, etc.
 Use  (auto-restart) and 
(ride-through control).
 The load is too large.  Use an inverter with a larger rating.
 Reduce f300(PWM carrier frequency)
to 4kHz or less.

000E Motor overload
 The V/F setting is improper.  Check the V/F parameter setting.
 The motor is locked up.  Check the load (operated machine).
 Low-speed operation is performed
continuously.
 An excessive load is applied to the motor
during operation.
 Adjust  to the overload that the
motor can withstand during operation in a
low speed range.

003E Main module
overload
 The carrier frequency is high and load
current has increased at low speeds
(mainly at 15Hz or less).
 Raise the operation frequency.
 Reduce the load.
 Reduce f300: PWM carrier frequency.
 When an operating motor is started up at
0Hz, use the auto-restart function.
 Set f316=1 (Carrier frequency with
automatic reduction).
*

0020 Over-torque trip
 Over-torque reaches to a detection level
during operation.
 Enable  (over-torque trip selection).
 Check system error.

0010 Overheat
 The cooling fan is life or fault
.
 The cooling fan requires replacement if it
does not rotate during operation.
Contact your Toshiba distributor.
 The ambient temperature is high or low
outside a specified ambient temperature.
 Operate at a specified ambient
temperature.
 The vent of the cooling fan is blocked up.  Secure sufficient space around the inverter.
 A heat generating device is installed close
to the inverter.
 Do not place any heat generating device
near the inverter.
 The load is large.  Reduce the load.
 Reduce f300: PWM carrier frequency.
 Set f316=1 (Carrier frequency with
automatic reduction).
 The temperature sensor is fault.
(Even if it resets after much time, When
always generating)
 Contact your Toshiba distributor.
* You can select a trip ON/OFF by parameters.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
