Example Read: 68 03 03 68 21 89 0B B5 16 (GA=21h)
RS485: Response: - Variant 1: 68 08 08 68 21 00 0B 01 0A 0A 0A 00 4B 16
- Variant 2: 68 0A 0A 68 21 00 0B 01 0A 0A 08 00 0C 00 55 16)
Write: - Variant 1: 68 08 08 68 21 69 0B 01 0A 0A 0A 00 B4 16 (GA=21h)
- Variant 2: 68 0A 0A 68 21 69 0B 01 0A 0A 08 00 0C 00 BE 16
Response: 10 21 00 21 16
Reference: FEZU
4.7.2. BRAT command
Syntax Read: LBRAT
RS232/USB: Response: ABRAT n bbbb
Write: SBRAT n bbbb
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Syntax: Read:
RS485:
Response:
Write:
Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Description: Setting and querying the baud rate "bbbb", in 0.1 kBaud, and the interface with number
"n" (1=RS232, 2=RS485 and 3=USB). The following baud rate values are valid: 9.6
kBaud, 19.2 kBaud, 38.4 kBaud, 57.6 kBaud and 115.2 kBaud.
The acknowledgement is already transmitted with the new baud rate.
Example Read: LBRAT 1
RS232/USB: Response: ABRAT 1 0096 (RS232 interface, 9600 Baud)
Write: SBRAT 1 0096 (RS232 interface, 9600 Baud)
Response: QOK00
Example Read: 68 04 04 68 21 89 0A 01 B5 16 (GA=21h)
RS485: Response: 68 06 06 68 21 00 0A 01 60 00 8C 16
Write: 68 06 06 68 21 69 0A 01 60 00 F5 16 (GA=21h)
Response: 10 21 00 21 16 (GA=21h)
Reference: --
4.7.3. BSTZ command
Syntax Read: LBSTZ
RS232/USB: Response: ABSTZ hhhhhh:mm:ss
Syntax: Read: Control set, BI = 6Fh
RS485: Response:
Description: Querying the status of the operating hours counter in hours "hhhhhhhh" (0...999999),
minutes "mm" (0...59) and seconds "ss" (0...59). The time units are separated by a colon
":".
Example Read: LBSTZ
RS232/USB: Response: ABSTZ 000176:34:15
Example Read: 68 03 03 68 21 89 6F 19 16 (GA=21h)
RS485: Response: 68 08 08 68 21 00 6F 2B 18 49 00 00 1C 16
Reference: ZYKL
4.7.4. EINS command
Syntax Read: LEINS
RS232/USB: Response: AEINS abcd efgh
Write: SEINS abcd efgh
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Long set with DB0, BI = 0Ah
DB0
n
Long set with DB0…DB2
DB2
DB1
DB0
H byte
L byte
bbbb
n
Long set with DB0…DB2, BI = 0Ah
DB2
DB1
DB0
H byte
L byte
bbbb
n
Long set with DB0…DB4
DB4
DB3
DB2
DB1
DB0
H byte
M byte
L byte
hhhhhh
mm
ss
