16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 33 of 66
Write:
Response: short set, OK or error acknowledgement; response time max. 1 ms
Release: in all states
Description: Setting and querying the temperature setpoint "sss" in °C of the PIREG-C2. Depending
on the selected configuration of the PIREG-C2, either the voltage at the setpoint input or
the setpoint specified with this command is used as setpoint. This command is only effec-
tive if the setpoint is controlled via the interfaces with the SKONF command. The nominal
temperature "sss" is monitored at the height of the temperature range.
Example Read: LSOLW
RS232/USB: Response: ASOLW 185
Write: SSOLW 185
Response: QOK00
Example Read: 68 03 03 68 21 89 35 DF 16 (GA=21h)
RS485: Response: 68 05 05 68 21 00 35 B9 00 0F 16
Write: 68 05 05 68 21 69 35 B9 00 78 16 (GA=21h)
Response: 10 21 00 21 16
Reference: KONF, SWEI
4.7.27. STEU command
Syntax Read: LSTEU
RS232/USB: Response: ASTEU abc def
Syntax: Read: Control set, BI = 36h
RS485: Response:
Description: Querying the states of the manual control inputs "abc" and the control states via the
PIREG-C2's "def" interface.
Assignment
a Manual start input: 0= not actuated 1= actuated
b Manual calibration input: 0= not actuated 1= actuated
c Manual reset input: 0= not actuated 1= actuated
d Control state start: 0= not set 1= set
e Control state calibration: 0= not set
1= calibration set
2= single-point Tc correction
f Control state reset: 0= not set 1= set
Example Read: LSTEU
RS232/USB: Response: ASTEU 100 000
Example Read: 68 03 03 68 21 89 36 E0 16 (GA=21h)
RS485: Response: 68 04 04 68 21 00 36 01 58 16
Reference: STST, STRS, STKA
4.7.28. STKA command
Syntax Write: SSTKA z
RS232/USB: Response: OK or error acknowledgement; response time max. 1 ms
Release: in all states (effective only in the OFF state)
Syntax: Write:
RS485:
Response: short set, OK or error acknowledgement; response time max. 1 ms
Release: in all states (effective only in the OFF state)
Description: Setting the following control states for calibration:
Assignment
0 Home position: Calibration and single-point Tc correction are started from the
home position.
1 Calibration control state: Calibration of the controller (provided it is switched off
or in an error state) is started when z= 1 is set. Before calibration can be restart-
ed the state must be reset. The calibration control state is functionally connected
in parallel to the calibration input.
Long set with DB0 and DB1, BI = 02h
Long set with DB0, BI = 38h
