16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 19 of 66
Syntax: Read: Control set, BI = 02h
RS485: Response: Long set with DB0 and DB1
Write: Long set with DB0 and DB1, BI = 02h
Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Description: Setting and querying the setting switches of the PIREG-C2. The setting switches have
the same function as the ten DIP switches on the PIREG-C2 without bus system. The
KONF command is used to select whether the DIP switches or the setting switches are to
be used.
Assignment
a Heating ramp of the heating conductor:
0= without 1= 2 s 2= 3 s 3= 5 s
b Temperature coefficient of the heating conductor:
0= Tc1= 7.46x10
-4
1/K, Tc2= 0, Tc3=0 (Alloy L)
1= Tc1= 10.8x10
-4
1/K, Tc2= 0, Tc3=0 (Alloy A20)
2= Tc1= 48.3x10
-4
1/K, Tc2= -6.12x10
-6
1/K², Tc3=2.80x10
-9
1/K³ (NOREX)
3= Tc1= 8.62x10
-4
1/K, Tc2= 0, Tc3=0 (Alloy M)
4= Setting with SEIPA TK command
5= Tc1= 12.35x10
-4
1/K, Tc2= -0.50 x10
-6
1/K², Tc3= 0.12 x10
-9
1/K³ (Alloy A20C)
c Calibration comparison time: 0= 15 s 1= 30 s
d Temperature range: 0= 0...300 °C 1= 0...500 °C
2= Setting with SEIPA TB command
e Calibration type: 0= new calibration after a power on or reset
1= calibration storage
f Transformer type: 0= sealing transformer with EI or UI-iron core
1= sealing transformer with toroidal iron core
g Reference: 0= reference temp. 20 °C for calibration
temperature 1 = variable reference temperature 0 - 50 °C for calibration
2= setting with SEIPA BT command
h 8-point Tc correction: 0= without 8-point Tc correction
1= with 8-point Tc correction
Example Read: LEINS
RS232/USB: Response: AEINS 0100 1000
Write: SEINS 0100 1000
Response: QOK00
Example Read: 68 03 03 68 21 89 02 AC 16 (GA=21h)
RS485: Response: 68 05 05 68 21 00 02 20 01 44 16
Write: 68 05 05 68 21 69 02 04 01 91 16 (GA=21h)
Response: 10 21 00 21 16
Reference: KONF, EIPA
4.7.5. EIPA command
Syntax Read: LEIPA BT Read reference temperature
RS232/USB: Response: AEIPA BT ttt
Write: SEIPA BT ttt Set reference temperature
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Read: LEIPA TB Read temperature range
Response: AEIPA TB ttt
Write: SEIPA TB ttt Set temperature range
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Read: LEIPA TK Read temperature coefficients
Response: AEIPA TK ±aaaa ±bbbb ±cccc sss ddd ; response time max. 6 ms
Write: SEIPA TK ±aaaa ±bbbb ±cccc Set temperature coefficients
Response: AEIPA TK sss ddd ; response time max. 26 ms
Release: not in the On or calibration state
