Toss PIREG-C2 - Configuration Parameters; Parameter Data; AHUE Parameter Data

16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 43 of 66
43
In-
stance
Attrib-
ute
Data type
Assign-
ment:
Description:
150
(96h)
3
Array of
BYTE
Consumer
Data
Write process data (WPD, Consuming Data), see
below
4
UINT
Size
Number of bytes for the read process data (e.g. 4)
Byte
Assignment:
Description
7
6
5
4
3
2
1
0
0
L byte (bits 0...7)
Setpoint (0…500 °C) in °C (see SOLW)
1
H byte (bits 8…15)
2
-
-
-
STRS
(z)
k2
k1
k0
STST
(z)
Control states:
Assignment of parameter ST see command STST
Assignm. of parameters k0…2 see command STKA
Assignment of parameter RS see command STRS
3
-
-
-
z
n3
n2
n1
n0
Assignment of parameter n0…3 see command KANR
Assignment of parameter z see command MEPA
4.10.3. Configuration parameters
In the parameter data, a distinction is made (see 4.11, Access - P / - K) between pure parameter data (P)
and configuration parameters (C). The configuration parameters are normally sent to the PIREG-C2 by
the parent controller during booting. The configuration parameters are stored in the PIREG-C2.
Read access: CIP object class: 04h (Assembly Object)
CIP object instance service: 0Eh (Get Attribute Single)
Instance: C8h (Configuration instance)
Attribute: 3
Write access: CIP object class: 04h (Assembly Object)
CIP object instance service: 10h (Set Attribute Single)
Instance: C8h (Configuration instance)
Attribute: 3
4.11. Parameter data
The acyclic read (RPa) and write parameter data (WPa) are read (T  O) or written (O  T) by the con-
trol. The write parameter data is monitored for the limits and releases specified in the respective com-
mand description and discarded in the event of an error.
Read access: CIP object class: A2h (ADI Object)
CIP object instance service: 0Eh (Get Attribute Single)
Write access: CIP object class: A2h (ADI Object)
CIP object instance service: 10h (Set Attribute Single)
Configuration parameters: In the parameter data, a distinction is made between pure parameter data
(P) and configuration parameters (C). The configuration parameters are normally sent to the PIREG-C2
by the parent controller during booting. The configuration parameters are initially not stored.
Parameter 90, "Configuration parameters store and restore", can be used to store and restore the config-
uration parameters in the PIREG-C2.
4.11.1. AHUE parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
1
Heating monitoring, activation
1
SHORT_STRING
Name
“AHUE Aktivierung”
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Activation (0/1)
2
Heating monitoring, temperature lower limit
1
SHORT_STRING
Name
“AHUE Temp. Ug.”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa -C)
5
USINT
Value
Lower limit (5…99 °C)
