Setting parameter, temperature coefficient Tc3
1
SHORT_STRING
Name
“EIPA TK Tk3”
2
USINT
Data type
C3h (INT)
3
USINT
Data length
2
4
USINT
Access
03h (RPa/WPa - C)
5
INT
Value
Temperature coefficient Tc3 (-9999…+9999)
20
Setting parameter, temperature ranges for continuity
1
SHORT_STRING
Name
“EIPA ST Temp.-B.”
2
USINT
Data type
C7h (UINT)
3
USINT
Data length
2
4
USINT
Access
01h (RPa - P)
5
UINT
Value
Temperature ranges for continuity (0…500 °C)
20
Setting parameter, temperature ranges for dynamics
1
SHORT_STRING
Name
“EIPA DY Temp.-B.”
2
USINT
Data type
C7h (UINT)
3
USINT
Data length
2
4
USINT
Access
01h (RPa - P)
5
UINT
Value
Temperature ranges for dynamics (0…500 °C)
4.11.5. FEKO Parameterdaten
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
22
Error configuration, Temperature jump
1
SHORT_STRING
Name
„FEKO Temp.-Spr.“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa – C)
5
USINT
Value
Configuration Temperature jump (0/1)
4.11.6. GWPA parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
30
Parameter selected for the next calibration.
1
SHORT_STRING
Name
“GWPA Gew. Param.”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
20
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Parameter selected for next calibration:
Byte 0: Length
Byte 1: not used
Byte 2…3: Calibration comparison time (d)
Byte 4…5: Calibration type (e)
Byte 6…7: Transformer type (f)
Byte 8…9: Tc correction (g)
Byte 10...11: Reference temperature (bbb)
Byte 12…13: Temperature range (ttt)
Byte 14…15: Tc1 of heating conductor (±aaaa)
Byte 16…17: Tc2 of heating conductor (±bbbb)
Byte 18…19: Tc3 of heating conductor (±cccc)
4.11.7. HZBG parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
31
Heating time limit
1
SHORT_STRING
Name
“HZBG Heizz.-Bg.”
2
USINT
Data type
C7h (UINT)
3
USINT
Data length
2
4
USINT
Access
03h (RPa/WPa - C)
5
UINT
Value
Maximum heating time (0…999) in 0.1s
