16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 34 of 66
2 Single-point Tc correction: Single-point Tc correction is set with z= 2. The state
is retained until it is reset. The single-point Tc correction can only be set when the
8-point Tc correction is not activated.
3 Saving Tc correction: The current 8-point or single-point Tc correction is saved
with z= 3 so that it is retained after a calibration. After this action was carried out
the device returns to the previous state.
4 Cancelling saving the Tc correction: Saving the Tc corrections is cancelled
with z= 4. After this action was carried out the device returns to the previous
state.
Example Write: SSTKA 1
RS232/USB: Response: QOK00
Example Write: 68 04 04 68 21 69 38 01 C3 16 (GA=21h)
RS485: Response: 10 21 00 21 16
Reference: STEU, KAPA
4.7.29. STRS command
Syntax Write: SSTRS z
RS232/USB: Response: OK or error acknowledgement; response time max. 1 ms
Release: in all states
Syntax: Write:
RS485:
Response: short set, OK or error acknowledgement; response time max. 1 ms
Release: in all states
Description: Setting of the reset "z" control state (1= set). A reset of the controller is triggered in this
state. The reset control state is functionally connected in parallel to the reset input. Once
the reset has been performed, the control state is reset.
Example Write: SSTRS 1
RS232/USB: Response: QOK00
Example Write: 68 04 04 68 21 69 39 01 C4 16 (GA=21h)
RS485: Response: 10 21 00 21 16
Reference: STEU
4.7.30. STST command
Syntax Write: SSTST z
RS232/USB: Response: OK or error acknowledgement; response time max. 1 ms
Release: in all states (effectiveness depends on state)
Syntax: Write:
RS485:
Response: short set, OK or error acknowledgement; response time max. 1 ms
Release: in all states (effectiveness depends on state)
Description: Setting of the start "z" control state (1= set). A sealing process is started in this state. The
sealing process is ended by resetting the control state. The start control state is function-
ally connected in parallel to the start input.
Example Write: SSTST 1
RS232/USB: Response: QOK00
Example Write: 68 04 04 68 21 69 3A 01 C5 16 (GA=21h)
RS485: Response: 10 21 00 21 16
Reference: STEU
4.7.31. TKEI command
Syntax Read: LTKEI
RS232/USB: Response: n;rrrr:bbbb (9 times)
Syntax: Read: Control set, BI = 72h
RS485: Response: Long set with DB0…DB4 (9 times)
Long set with DB0, BI = 39h
Long set with DB0, BI = 3Ah
