Description: Setting and querying the lower limit "uuu" and of the upper limit "ooo" in K (5…99 K) of
the temperature OK range and of the stabilisation time "sss" in 0.1 s (0…99.9 s) of the
temperature OK message. The temperature limits are the maximum allowed deviations of
the actual value from the target value. If the actual value is within the temperature OK
range, the temperature OK message is set.
The stabilisation time begins as soon as the actual value has reached the temperature
OK range. If the actual value leaves the temperature OK range during the stabilisation
time, the temperature OK message is not reset.
The temperature OK message is output with the OK output and is only effective if the
temperature OK message was selected with the SKONF command.
Example Read: LTOKG
RS232/USB: Response: ATOKG 010 010 010
Write: STOKG 010 010 010
Response: QOK00
Example Read: 68 03 03 68 21 89 08 B2 16 (GA=21h)
RS485: Response: 68 07 07 68 21 00 08 0A 0A 0A 00 47 16
Write: 68 07 07 68 21 69 08 0A 0A 0A 00 B0 16 (GA=21h)
Response: 10 21 00 21 16
Reference: KONF
4.7.34. TUEE command
Syntax Read: LTUEE
RS232/USB: Response: ATUEE a uuu ooo sss
Write: STUEE a uuu ooo sss
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Syntax: Read: Control set, BI = 09h
RS485: Response:
Write: Long set with DB0…DB4, BI = 09
Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Description: Setting and reading the parameter of the temperature monitoring. The temperature moni-
toring is a monitoring function, that can be switched on with "a" (a=1) and switched off
(a=0). A temperature OK range around the nominal value is set with lower limit "uuu" and
upper limit "ooo" in K (5…99 K). If the actual value leaves this range during sealing, once
the range has already been reached the PIREG-C2 controller goes into error (error 8).
The stabilisation time "sss" in 0.1s (0…99.9 s) begins as soon as the actual value has
reached the temperature OK range. If the actual value leaves the temperature OK range
during the stabilisation time, the PIREG-C2 controller does not go into error. In the event
of a change of the target value by more than 2 °C, the stabilisation period is restarted.
Example Read: LTUEE
RS232/USB: Response: ATUEE 1 010 010 010
Write: STUEE 1 010 010 010
Response: QOK00
Example Read: 68 03 03 68 21 89 09 B3 16 (GA=21h)
RS485: Response: 68 08 08 68 21 00 09 01 0A 0A 0A 00 49 16
Write: 68 08 08 68 21 69 09 01 0A 0A 0A 00 49 16 (GA=21h)
Response: 10 21 00 21 16
Reference: FEZU
4.7.35. UIMW command
Syntax Read: LUIMW
RS232/USB: Response: AUIMW uuuuu vvvvv iiiii ccccc
Release: only in OFF and ON state
