Alarm output activation: Alarm output is set in the event of a malfunction
following initial heating
Alarm output switching type: Relay point closed during alarm
OK output activation: Standard: Calibration OK message
For device type x02: Calibration no. message:
OK output switching type: Relay point closed during OK
Cal. Input pulse contr.: no pulse control
Actual value output feature: Actual value output (0…10V)
Setting parameters (SEIPA):
Reference temperature: 20°C
Temperature range: 200°C
Temperature coefficients: Tc1= +3.00 x10-4 1/K, Tc2= -0.01 x10-9 1/K
Tc3= -0.01 x10-9 1/K
Modulation reserve (SKASR):
Modulation reserve: 20%
P-factor correction value (SKPFK):
P-factor correction value: 0 (no P-factor correction value)
Heating time of auto Tc correction (SKTKZ):
Heating time: 0 s (no auto Tc correction)
Setting of calibration 1…8 (LKAPK n):
all parameters: 0 (clear storage of Tc correction)
Temperature OK message (STOKG):
Temperature lower limit: 5 K Stabilisation time: 0
Temperature upper limit: 5 K
Temperature monitoring (STUEE):
Activation: Off Temperature lower limit: 5 K
Stabilization time: 0 Temperature upper limit: 5 K
Heating monitoring (SAHUE):
Activation: Off Temperature lower limit: 5 K
Heating time: 0 Temperature upper limit: 5 K
Variant: 1 (heating time lower limit 1023)
P-factor monitoring (SPFUE):
Activation: Off Lower limit: 1
Upper limit: 100
Heating time limit (SHBZG):
maximum heating time: 0 (Off)
Communication monitoring (SKOUE):
For all interfaces: Activation: Off Downtime: 0
Communication configuration (SKOKO):
Addressed RS232 communication: Off
Interfaces:
Baud rate for all interfaces (SBRAT): 9600 Baud
Device address for RS485 communication (SGADR): 0
Setting of controller calibration 1…8 (LREEK n, LTKEK n):
all parameters: 0
Counter (SZYKL):
Calibration cycle counter 1…8: 0
Error configuration (SFEKO): (from V1.01/1.06/1.06)
all error messages: active
Error memory:
Contents: deleted
Example Write: SWESE 1
RS232/USB: Response: QOK00
Example Write: 68 04 04 68 21 69 0C 01 97 16 (GA=21h)
RS485: Response: 10 21 00 21 16
Reference: --
4.7.38. ZUST command
Syntax Read: LZUST
RS232/USB: Response: AZUST bb kk
Syntax: Read: Control set, BI = 37h
RS485: Response:
