Toss PIREG-C2 - ZYKL Command

16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 39 of 66
39
Description: Querying the state of the PIREG-C2 with the following assignments:
Assignment
bb Operating state: 0= Initialisation 4= Error state
1= OFF state 5= Calibration state
2= ON state 6= Reset state
3= Calibration state
kk Calibration state: 0= Ok
1= initialise calibration
2= calibrate input amplifier
3= determine the phase shift
4= determine the reference resistance (R20)
5= calibration comparison time
6= check reference resistance (R20)
7= determine the P-factor
8= set initialising remanence
9= 8-point Tc correction
10= save controller settings
11= initialise single-point Tc correction
12= single-point Tc correction Off
13= single-point Tc correction heating
14= set and save single-point Tc correction
20= calibration switchover
Example Read: LZUST
RS232/USB: Response: AZUST 01 00
Example Read: 68 03 03 68 21 89 37 E1 16 (GA=21h)
RS485: Response: 68 04 04 68 21 00 37 01 59 16
Reference: FEZU
4.7.39. ZYKL command
Syntax Read: LZYKL n
RS232/USB: Response: - Total cycle counter: AZYKL 0 ggggggggg
- Cal. cycle counter 1…8: AZYKL n zzzzzzz
Write: - Cal. cycle counter 1…8: SZYKL n
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Syntax: Read:
RS485:
Response: - Total cycle counter: Long set with DB0…DB4
DB4
DB3
DB2
DB1
DB0
Byte 3
Byte 2
Byte 1
Byte 0
ggggggggg
n
- Calibration cycle counter: Long set with DB0…DB3
DB3
DB2
DB1
DB0
Byte 2
Byte 1
Byte 0
zzzzzzz
n
Write: - Calibration cycle counter: Long set with DB0, BI = 6Eh
DB0
0
Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Description: Querying the "zzzzzzz" (0...9999999) sealing cycles performed by the PIREG-C2 for the
stored calibrations (parameters "n"=1...8) and the total number of "ggggggggg"
(0…999999999) sealing cycles performed by PIREG-C2 with the value zero for the pa-
rameter "n".
The calibration cycle counters (1...8) are set to zero by transferring the parameter "z" with
the respective number (1...8) of the calibration cycle counter.
Example Read: LZYKL 0
RS232/USB: Response: AZYKL 0 000018553 (total cycle counter)
Write: - Calibration cycle counter: SZYKL 1
Response: QOK00
Long set with DB0, BI = 6Eh
DB0
n
