Toss PIREG-C2 - TKEK Command; TOKG Command

16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 35 of 66
35
Description: Read out the determined temperatures for the controller "rrrr" and for the heating tape
"bbbb", in 0.1°C, for the points "n" (0...8) during the 8-point Tc correction of the current
calibration. At undefined temperatures, the value zero is output. For the RS232 and USB
interfaces, the output is in CSV format.
In RS485 communication, the nine long sets of the response are sent one after the other
with a pause of 3ms each.
Example Read: LTKEI
RS232/USB: Response: 0;0251;0273
1;0500;0569
…
8;2400;2761
Example Read: 68 03 03 68 21 89 72 1C 16 (GA=21h)
RS485: Response: 68 08 08 68 21 00 72 01 FB 00 11 01 A1 16
68 08 08 68 21 00 72 02 F4 01 39 02 C5 16
…
68 08 08 68 21 00 72 08 60 09 C9 0A D7 16
Reference: REEI, REEK, TKEK
4.7.32. TKEK command
Syntax Read: LTKEK k
RS232/USB: Response: k;n;rrrr:bbbb (9 times)
Syntax: Read:
RS485:
Response: Long set with DB0…DB5 (9 times)
DB5
DB4
DB3
DB2
DB1
DB0
H byte
L byte
H byte
L byte
bbbb
rrrr
n
k
Description: Read out the determined temperatures for the controller "rrrr" and for the heating tape
"bbbb", in 0.1°C, for the points "n" (0...8) during the 8-point Tc correction of the calibration
"k" (1…8).. At undefined temperatures, the value zero is output. For the RS232 and USB
interfaces, the output is in CSV format.
In RS485 communication, the nine long sets of the response are sent one after the other
with a pause of 3ms each.
Example Read: LTKEI
RS232/USB: Response: 1;0;0251;0273
1;1;0500;0569
…
1;8;2400;2761
Example Read: 68 04 04 68 21 89 73 01 1E 16 (GA=21h)
RS485: Response: 68 09 09 68 21 00 73 01 00 FB 00 11 01 A2 16
68 09 09 68 21 00 73 01 01 F4 01 39 02 C6 16
…
68 09 09 68 21 00 73 01 08 60 09 C9 0A D9 16
Reference: REEI, REEK, TKEI
4.7.33. TOKG command
Syntax Read: LTOKG
RS232/USB: Response: ATOKG uuu ooo sss
Write: STOKG uuu ooo sss
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Syntax: Read: Control set, BI = 08h
RS485: Response:
Write:
Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Long set with DB0, BI = 73h
DB0
k
Long set with DB0…DB3
DB3
DB2
DB1
DB0
H byte
L byte
sss
ooo
uuu
Long set with DB0…DB3, BI = 08h
DB3
DB2
DB1
DB0
H byte
L byte
sss
ooo
uuu
