Assignment Settings:
d Calibration comparison time: 0= 15 s 1= 30 s
e Calibration type: 0= new calibration after a power on or reset
1= calibration storage
f Transformer type: 0= sealing transformer with EI or UI-iron core
1= sealing transformer with toroidal iron core
g Temperature coefficient correction:
0= without temperature coefficient correction
1= with 8-point Tc correction
2= with single-point Tc correction
3= 8-point Tc correction saved
4= single-point Tc correction saved
Example Read: LKAPA
RS232/USB: Response: AGWPA 1100 020 300 +1080 +0000 +0000
Example Read: 68 03 03 68 21 89 05 AF 16 (GA=21h)
RS485: Response: 68 0E 0E 68 21 00 05 03 14 00 2C 01 38 04 00 00 00 00 A6 16
Reference: GWPA, EINS, STKA
4.7.17. KAPK command
Syntax Read: LKAPK n
RS232/USB: Response: AKAPK n defg bbb ttt ±aaaa ±bbbb ±cccc rrr zzz ppp
Syntax: Read:
RS485:
Response: Long set with DB0…DB15
DB7
DB6
DB5
DB4
DB3
DB2
DB1
DB0
H byte
L byte
H byte
L byte
H byte
L byte
±aaaa
ttt
bbb
defg
n
DB15
DB14
DB13
DB12
DB11
DB10
DB9
DB8
H byte
L byte
H byte
L byte
H byte
L byte
ppp
zzz
rrr
±cccc
±bbbb
DB1
7
6
5
4
3
2
1
0
-
-
g3
g2
g1
f
e
d
Description: Querying the following parameters of the calibrated calibration (1...8) of the PIREG-C2
controller:
- Settings "defg" (see below)
- Reference temperature "bbb" (0...50, 255 with variable reference temperature) in 1 °C
- Temperature range "ttt" (100...500) in 1 °C
- Temp. coeffic. of the heating conductor Tc1 "±aaaa" (+300…+9999) in 0.01x10
-4
1/K
- Temp. coeffic. of the heating conductor Tc2 "±bbbb" (-9999…+9999) in 0.01x10
-6
1/K
2
- Temp. coeffic. of the heating conductor Tc3 "±cccc" (-9999…+9999) in 0.01x10
-9
1/K
3
- Modulation reserve "rrr" (000= auto modulation reserve, 20...100 %) in 1 %
- Heating time for automatic Tc correction "zzz" (0...999 s) in 1 s
- P-factor correction value "ppp" in % (0, 30…110 %)
If the heating time "zzz" is equal to zero, the Tc correction is controlled via the start input.
If the P-factor correction value "ppp" is equal to zero, the controller operates with the cali-
brated P-factor.
Assignment Settings:
d Calibration comparison time: 0= 15 s 1= 30 s
e Calibration type: 0= new calibration after a power on or reset
1= calibration storage
f Transformer type: 0= sealing transformer with EI or UI-iron core
1= sealing transformer with toroidal iron core
g Temperature coefficient correction:
0= without temperature coefficient correction
1= with 8-point Tc correction
2= with single-point Tc correction
3= 8-point Tc correction saved
4= single-point Tc correction saved
Example Read: LKAPK 1
RS232/USB: Response: AKAPK 1 0100 020 300 +1080 +0000 +0000 040 888 095
Long set with DB0, BI = 13h
DB0
n
