Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Description: Setting and querying the P-factor correction value "ppp" in % (0, 30...110%) for the cur-
rent active calibration (1...8). The calibrated P-factor of the controller is adjusted in per-
cent using the P-factor correction value: If the P-factor correction value is equal to zero,
the controller will be running with the calibrated P-factor
Example Read: LKPFK
RS232/USB: Response: AKPFK 080
Write: SKPFK 080
Response: QOK00
Example Read: 68 03 03 68 21 89 0F B9 16 (GA=21h)
RS485: Response: 68 04 04 68 21 00 0F 50 80 16
Write: 68 04 04 68 21 69 0F 50 E9 16 (GA=21h)
Response: 10 21 00 21 16
Reference: factory settings
4.7.23. KTKZ command
Syntax Read: LKTKZ
RS232/USB: Response: AKTKZ ttt
Write: SKTKZ ttt
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Syntax: Read: Control set, BI = 0Eh
RS485: Response:
Write:
Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Description: Setting and querying the heating time "ttt" in 1s (0...999s) for the automatic execution of
the 8-point Tc correction during calibration and the single-point Tc correction using the
TM6 thermometer. After the heating time has elapsed, the PIREG-C2 moves to the next
temperature step in the 8-point Tc correction or ends the single-point Tc correction. If the
heating time is equal to zero, the temperature coefficient corrections are controlled via the
start input.
Example Read: LKTKZ
RS232/USB: Response: AKTKZ 120
Write: SKTKZ 120
Response: QOK00
Example Read: 68 03 03 68 21 89 0E B8 16 (GA=21h)
RS485: Response: 68 05 05 68 21 00 0E 78 00 A7 16
Write: 68 05 05 68 21 69 0E 78 00 10 16 (GA=21h)
Response: 10 21 00 21 16
Reference: factory settings
4.7.24. MEPA command
Syntax Read: LMEPA
RS232/USB: Response: AMEPA z
Write: SMEPA z
Response: OK or error acknowledgement; response time max. 1 ms
Release: only in OFF state
Syntax: Read: Control set, BI = 3Dh
RS485: Response:
Write:
Long set with DB0 and DB1
DB1
DB0
H byte
L byte
ttt
Long set with DB0 and DB1, BI = 0Eh
DB1
DB0
H byte
L byte
ttt
Long set with DB0
DB0
z
Long set with DB0, BI = 3Dh
DB0
z
