16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 49 of 66
49
44
Configuration, Activation of the alarm output
1
SHORT_STRING
Name
„KONF Alarm-Ausg.“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Activation of the alarm output (0/1)
45
Configuration, Alarm output switching type
1
SHORT_STRING
Name
„KONF Alarm SArt“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Alarm output switching type (0/1)
46
Configuration, OK output activation
1
SHORT_STRING
Name
„KONF Ok-Ausg.“
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
OK output activation (0…3)
47
Configuration, OK output switching type
1
SHORT_STRING
Name
„KONF Ok SArt“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
OK output switching type (0/1)
48
Configuration,
Pulse control of the calibration start input
1
SHORT_STRING
Name
„KONF Kal.-Eing.“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Pulse control of the calibration start input (0/1)
49
Configuration, Actual value output feature
1
SHORT_STRING
Name
„KONF Istw.-Ausg.“
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Actual value output feature (0…3)
4.11.11. KPFK parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
50
P-factor correction,
this value will be used for all 8 calibration
1
SHORT_STRING
Name
“KPFK P-Fak.-Kor.”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa -C)
5
USINT
Value
P-factor correction value in % (0, 30…110)
