Toss PIREG-C2 - KTKZ Parameter Data; PFUE Parameter Data; TKEK Parameter Data

16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 50 of 66
50
4.11.12. KTKZ parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
51
Heating time of automatic Tc correction,
this value will be used for all 8 calibration
1
SHORT_STRING
Name
“KTKZ Aufheizzeit”
2
USINT
Data type
C7h (UINT)
3
USINT
Data length
2
4
USINT
Access
03h (RPa/WPa - C)
5
UINT
Value
Heating time for auto. Tc correction in s (0…999)
4.11.13. PFUE parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
52
P-factor monitoring, activation
1
SHORT_STRING
Name
“PFUE Aktivierung”
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Activation (0/1)
53
P-factor monitoring, lower limit
1
SHORT_STRING
Name
“PFUE Untergrenze”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
P-factor lower limit (1…99)
54
P-factor monitoring, upper limit
1
SHORT_STRING
Name
“PFUE Obergrenze”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
P-factor upper limit (2…100)
55
P-factor monitoring, calibrated P-factor (ppp) of the
current calibration (1…8)
1
SHORT_STRING
Name
“PFUE kal. P-Fak.”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Calibrated P-factor (ppp)
4.11.14. TKEK parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
56
8-point Tc correction of calibration 1
Temperature for controller and heating tape
1
SHORT_STRING
Name
“TKEK Kal. 1”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
56
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Controller and heating tape temperatures of the 8-
point Tc correction of calibration 1:
Byte 0: Length
Byte 1: not used
Byte 2…3: Tc point 0, here 0
Byte 4…5: Temp. of controller (rrrr) in 0.1°C
Byte 6…7: Temp. of heat. tape (bbbb) in 0.1°C
Byte 8…9: Tc point 1, here 1
Byte 10…11: Temp. of controller (rrrr) in 0.1°C
Byte 12…13: Temp. of heat. tape (bbbb) in 0.1°C
