16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 56 of 66
4.12. EtherNet/IP reset
When communicating via the EtherNet/IP interface, the PIREG-C2 has two options for triggering a reset.
Either the reset command STRS in the process and parameter data or the reset access (05h) to the iden-
tity object (01h) can be used.
For the reset access to the identity object (01h), the two following reset types are available. When both
reset types are executed, the PIREG-C2 then carries out its own reset.
Type 0: Power-on reset
Type 1: Factory settings
4.12.1 Power-on reset
The power-on reset (type 1) sets the EtherNet/IP interface and the PIREG-C2 to the same state as after
power-on.
Write access: CIP object class: 01h (Identity Object)
CIP object instance service: 05h (Reset)
Instance: 1
Attribute: empty
Data: 00h (1 byte)
4.12.2 Factory settings
With the reset for the factory settings (type 2) the settings of the EtherNet/IP interface are reset to the
factory settings of HMS. For example, the IP address is also set to zero. The PIREG-C2 performs a pow-
er-on reset.
Write access: CIP object class: 01h (Identity Object)
CIP object instance service: 05h (Reset)
Instance: 1
Attribute: empty
Data: 01h (1 byte)
4.13. Manual IP address
The IP address for the EtherNet/IP interface of the PIREG-C2 can be set either via the EtherNet/IP net-
work or manually on the PIREG-C2 with two rotary coding switches.
The rotary coding switches are used to define the lowest byte of the IP address. The setting of
the rotary coding switches is only read directly after switching on or after a reset. The following
specifications exist:
Manual IP address, default: 192.168.001.xxx
Setting of rotary coding switch:
00: The set IP address is retained or the IP address is set via the EtherNet/IP network.
01…FE: Set manual IP address with xxx = 001…254 (01…FE
Hex
)
FF: Reset the PIREG-C2 and EtherNet/IP interface to the factory settings.
