Setting switch, Temperature range
1
SHORT_STRING
Name
„EINS Temp.-B.“
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa – C)
5
USINT
Value
Temperature range (0…2)
11
Setting switch, Calibration type
1
SHORT_STRING
Name
„EINS Kal.-Art“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa – C)
5
USINT
Value
Calibration type (0/1)
12
Setting switch, Transformer type
1
SHORT_STRING
Name
„EINS Trafo-Typ“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa – C)
5
USINT
Value
Transformer type (0/1)
13
Setting switch, Reference temperature
1
SHORT_STRING
Name
„EINS Bz-Temp.“
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa – C)
5
USINT
Value
Reference temperature (0…2)
14
Setting switch, 8-point Tc correction
1
SHORT_STRING
Name
„EINS Tk-Korr.“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa – C)
5
USINT
Value
8-point Tc correction (0/1)
4.11.4. EIPA parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
15
Setting parameter, reference temperature
1
SHORT_STRING
Name
“EIPA BT Bz-Temp.”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Reference temperature (0…50 °C)
16
Setting parameter, temperature range
1
SHORT_STRING
Name
“EIPA TB Temp.-B.”
2
USINT
Data type
C7h (UINT)
3
USINT
Data length
2
4
USINT
Access
03h (RPa/WPa - C)
5
UINT
Value
Reference temperature (100…500 °C)
17
Setting parameter, temperature coefficient Tc1
1
SHORT_STRING
Name
“EIPA TK Tk1”
2
USINT
Data type
C3h (INT)
3
USINT
Data length
2
4
USINT
Access
03h (RPa/WPa - C)
5
INT
Value
Temperature coefficient Tc1 (+300…+9999)
18
Setting parameter, temperature coefficient Tc2
1
SHORT_STRING
Name
“EIPA TK Tk2”
2
USINT
Data type
C3h (INT)
3
USINT
Data length
2
4
USINT
Access
03h (RPa/WPa - C)
5
INT
Value
Temperature coefficient Tc2 (-9999…+9999)
